Jacuzzi Elara 72″ Acrylic Air Bathtub for Drop-In Installations with Right Drain and Basic Controls

Product Features:

• Durable high-gloss acrylic material
• Pure Air® bubbles provide gentle embracing massage
• Balanced 360° balanced air flow system for a whole body experience
• Sidewall, floor and/or TLC (Thermal Lumbar Comfort ) air inlets
• Limited lifetime manufacturer’s warranty for tub with 2 years warranty for labor and travel costs. Drilling for faucet mounting will NOT void the warranty.



Jacuzzi® Technology:



Product Specifications:

Variations:

About Jacuzzi® Jacuzzi® has become the world’s most recognized and largest selling brand of jetted / whirlpool baths and spas. In addition to the first whirlpool bath patent, Jacuzzi® has 250 worldwide patents for advancements in pump systems, jet technology, air controls and product design. This ongoing commitment to innovative product development ensures Jacuzzi’s leadership position in the industry, and sets standards the world over.

• TargetPro™ Jets: Jacuzzi® TargetPro™ jets offer incredible performance and comfort. With a low-profile face, easy to manipulate 60 degree range of adjustment, and simple low control, TargetPro™ allows you to tailor your experience.
• Sleek Linear Overflow: The linear overflow offers a contemporary look to your bath while providing exceptional overflow protection.
• Tru-Level™ Base: Ultra-high density foam levelers that provide support and easy leveling to simplify installation.
• Slip-Resistant Bottom: A matte texturing technique is applied under the clear coat to create an invisible yet effective traction area.
• Silent Air Induction: Jacuzzi’s patented air induction system silently mixes air into the water creating that legendary Jacuzzi® Whirlpool experience without a hissing sound.
• Pure Air® Features:
  • Automatic Purge: Drain activated system purges the air blowers after each use
  • 360° Balanced Air Flow: A unique network of channels that push heated air evenly into the bath
  • TLC: Thermal Lumbar Comfort area delivers heated air to your back
  • Pure Air® Wave Mode: Cycles blower from its minimum to a user defined maximum
  • Overall Height: 26″ (measured from the top of tub rim to the bottom of basin)
  • Overall Width: 36″ (measured from back most to front most point on outer rim)
  • Overall Length: 72″ (measured from left most to right most point on outer rim)
  • Basin Width (Bottom): 21-1/10″ (back to front measurement of the bottom of basin walls)
  • Basin Length (Bottom): 51″ (right to left measurement of the bottom of basin walls)
  • Basin Width (Top): 28″ (back to front measurement of the top of basin walls)
  • Basin Length (Top): 64″ (right to left measurement of the top of basin walls)
  • Water Depth: 17-7/10″ (depth of water at tub’s maximum capacity)
  • Maximum Water Capacity: 97 – gallons
  • Drain Location: Right
  • Blower Location: Left
  • Operating Gallons: 97
  • Drop-In Cutout Required: 70″ x 34″
  • ELA7236ARL2XX: This model
  • ELA7236WRL2HX: This model with Whirlpool Experience and Heater
  • ELA7236WRL4CW: This model with Whirlpool Experience and Luxury Controls
  • ELA7236CRL5CH: This model with Salon® Spa Experience, LCD Controls, Chromatherapy Lighting, and Heater
